A11.1508-06 Student Biological Microscope, Vertical Monocular Head

  • Monocular Vertical Head, Whole Body Inclination Adjustable
  • Total Magnification 40x~1600x Available
  • Coarse & Fine Focusing Knob, Focusing Range 50mm
  • Single Layer Stage With Vernial Scale Attached
  • Plan-Concave Mirror Dia. 40mm

Products Details

A11.1508 Student Biological Microscope 1 2 3 4 5 6
Head Mono Vertical Tube
Eyepiece 5x - -
10x
12.5x - - - -
15x - - - -
16x   - -
Objective 4x - - - -
10x
40x
100x - -
Nosepiece Triple Revolving Nosepiece
Stage Stage with Specimen Clips, Size110x120mm - - - -
Stage with Specimen Clips, Size120x120mm - -
Mechanical Slide Holder Vernial Scale - -
Condenser 5 Holes Disc Diaphragm - - - -
N.A.=1.25 with Iris Diaphragm & Filter - -
Focusing Separate Coarse and Fine Focusing Knobs
Coarse Fousing Range:50mm,
Fine Adjustment Range :1.8mm-2.2mm
Light Source Concave-Plan Mirror, Dia 50mm
Optional Accessories
Light Source Attachable Electrical Illuminator (110V/220V 20W) A56.1501
